G2 Axle and Gear C4TSR456AC0D G2 Core 44 Rear 4.56 30 Spl W/ARB Air Locker And Disc Brakes 97-06 Wrangler TJ/LJ G2 Axle and Gear
SKU ds_FCNB_C4TSR456AC0D
fast & Reliable
Sold and shipped out of the USA
Secure Payments
Financing Available
Trusted Brands
Top-Quality Suppliers
Sold out
Original price
$0.00
-
Original price
$0.00
Original price
$0.00
$0.00
-
$0.00
Current price
$0.00
Description
G2 Axle and Gear is proud to introduce our new CORE 44 axle housing for 1997-2006 Jeep TJ/LJ Wranglers. Utilizing the strongest and latest generation high pinion Dana 44 gear design, we have developed a whole new housing to handle the heavy loads that would normally bend a stock Dana 30 or Rubicon Dana 44. The CORE 44 will accept stock Dana 44 ring and pinions, axle shafts and all aftermarket lockers.
Details:
- Fits 1997 to 2006 TJ Wrangler, Rubicon and Unlimited
- Integrated skid plates on lower control arm mount
- Heavy-duty 1/4 Inch laser cut brackets
- Heavy duty 3 Inch diameter 5/16 Inch DOM tubes
- Reinforcing ribs for added strength and protection
- Heavy duty forged bearing caps
- Spanner nuts for backlash adjustment
- Heat-treated aluminum diff cover with cooling fins
- Utilizes new generation JK 44 ring and pinion
- Gear Ratio: 4.56
- Locker: ARB Air Locker
- SAE Bearings
- 30 Spline G2 Chromoly Axles
- With Disc Brake Conversion Kit
Specifications
| axle_type | Core 44 TJ |
| bolt_pattern | 5 on 4.5 |
| brake_type | Disc Brake Upgrade |
| brand_logo | https://www.asapnetwork.org/sites/default/files/brands/icons/G2_Logo_BlackText_CMYK.png |
| Class | ASEM2 |
| Description_ASM | Integrated skid plates on lower control arm mount;Heavy-duty 1/4in. laser cut brackets;Heavy duty 3in. diameter 5/16in. DOM tubes;Reinforcing ribs for added strength and protection;Heavy duty forged bearing caps;Spanner nuts for backlash adjustment;Heat-treated aluminum diff cover with cooling fins;Utilizes new generation JK 44 ring/pinion;Gear Ratio: 4.56;Locker: ARB AIR LOCKER;SAE Bearings;30 Spline G2 Chromoly Axles; w/Disc Brake Conversion Kit |
| Description_DEF | Drive Axle Shaft |
| Description_DES | CORE 44 Complete Axle Assembly |
| Description_DES | G2 Core 44 Rear TJ/LJ 4.56 W/Arb Air Locker W/Disc Brake Kit |
| Description_EXT | CORE 44 Complete Axle Assembly; 4.56 w/ARB Air Locker; 30 Spline; w/Disc Brake Kit; |
| Description_FAB | 30 Spline G2 Chromoly Axles |
| Description_FAB | Heat Treated Aluminum Differential Cover w/Cooling Fins |
| Description_FAB | Heavy Duty 1/4 in. Laser Cut Brackets |
| Description_FAB | Heavy Duty 3 in. Diameter 5/16 in. DOM Tubes |
| Description_FAB | Heavy Duty Forged Bearing Caps |
| Description_FAB | Integrated Skid Plates On Lower Control Arm Mount |
| Description_FAB | Massive Forged Inner C End |
| Description_FAB | Reinforcing Ribs For Added Strength And Protection |
| Description_FAB | SAE Bearings |
| Description_FAB | Spanner Nuts For Backlash Adjustment |
| Description_FAB | Utilizes New Generation JK 44 Ring And Pinion |
| Description_FAB | With Disc Brake Conversion Kit |
| Description_INV | G2 CORE 44 REAR |
| Description_LAB | Made In Logo |
| Description_LAB | Proposition 65 |
| Description_MKT | G2 Axle & Gear is proud to introduce our new CORE 44 axle housing for 1997-2006 Jeep TJ/LJ Wranglers. Utilizing the strongest and latest generation high pinion Dana 44 gear design, we have developed a whole new housing to handle the heavy loads that would normally bend a stock Dana 30 or Rubicon Dana 44. The CORE 44 will accept stock Dana 44 ring and pinions, axle shafts and all aftermarket lockers. |
| Description_SHO | Differential |
| gear_ratio | 4.56 Ratio |
| height | 20.0 |
| housing_type | Core 44 97-06 TJ |
| last_update | 2021-03-22 10:18:21 |
| length | 65.0 |
| Location | Rear |
| LTL | N |
| prop_65_warning | CALIFORNIA WARNING: Cancer and Reproductive Harm -www.P65Warnings.ca.gov |
| sold_as | Each |
| Universal | No |
| vehicle_type | Jeep |
| WARNING CA Proposition 65 | Yes |
| WARNING CA Proposition 65 Message | WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov. |
| weight | 320.0 |
| width | 42.0 |
